Preparation | Reliable Part Modelling 03

When my drawing office moved from 2D CAD to 3D CAD with Autodesk Inventor, we noticed a significant upturn in productivity. Why ?

AutoCAD has a single document environment. If one of your colleagues is working late on a project, it’s really hard to help them out.

Autodesk Inventor has a distributed file system. This means that we can split the work up amongst our colleagues and work in parallel on the same project.

One colleague works on these parts, one colleague works on those parts, one colleague could start putting parts into assemblies – you might even be able to start laying up drawings early in the design process.

But – for this to work, you need to be working as a team, and teams have ground rules, in this post we will take a look at the preparation you can do to  set your team up for success.

Click here to read part 02 of this Blog post series, to learn about design intent for Reliable part modelling.

You don’t have to agree with me on standards such as parameter naming or model orientation, but you do need to follow industry standards, or at least get everyone in your office to agree to work the same way!

Here are some topics that you’ll need to consider. Please feel free to copy and paste from this section for your CAD manual.

Tip : Click here to download the handout from class ‘Reliable Modelling Techniques for Complex Part Design in Inventor’ on Autodesk University online (It’s free) for a checklist to help you set up your environment.

X = Left/Right

Y = Up/Down

Z = In/Out

This is how Inventor is set up.

X = Left/Right

Y = Forward/Backward

Z = Up/Down

This is how AutoCAD is set up.

Engineering = Y Up

Architecture = Z Up

If you work with AutoCAD or Revit users, or you often share files with colleagues in the Architecture/Construction, you may want to model with ‘Z up’.

You can prepare your Inventor template to use ‘Z up’ by adjusting your view cube orientation and saving your file as the ‘Standard’ template (remember to do this for Parts, Assemblies and presentations).

You can’t edit or delete the Origin planes, but you can re-name them. Rename the Origin planes in your template files to match your view cube orientation to subtly reinforce your modelling orientation standard.

Parameters in Inventor represent placeholders for values that can change. Parameter names must follow some rules set down by Inventor.

To improve communication between users, it’s a good idea to agree on some conventions for parameter naming.

You might also want to consider if there are any standard named parameters that should be in every model file? If so – include them in your template (and should they be set to ‘export’ so that they can be read into the BOM/Parts List?).

Shorter parameter names are easier to remember and to type as you are modelling but can get obscure. All User Parameters should have a comment, to explain their function.

Some parameter names are reserved by Inventor and cannot be used. Please see the help for details.

Tip : Don’t forget that you can rename parameters on the fly. Type the formula:

‘Parameter name = Parameter Value’

into any input box to rename the parameter as it is created.

If you have more than a few features, it can be difficult for the next person who opens your model to work out how the features are related.

By renaming your features, you can provide an easy ‘Breadcrumb trail’ to guide your colleagues through your model’s structure.

In preparation to start modelling, give a little thought to the features in the design. Can you give them obvious, distinct and unique names?

Remember that Inventor will not let you give two features the same name, even if those features are of different types, so append the feature name with the feature type

Ext = Join Extrusion
Cut = Cut Extrusion
Rad = External Fillet (Radius)
Fil = Internal Fillet
Rev = Revolve
Mir = Mirror
Pat = Pattern

Tip : The ‘Show Extended Names’ Option will show additional information next to your features such as extrude length or Fillet Radius.

Turn on extended names, by clicking in the model browser > Hamburger menu > Display preferences > Show Extended names.

Or by visiting, Tools > Application options > Part [Tab] > ‘Display extended information after feature node name in browser’ [Check box].

Click on this link to read part 04 in this series and learn how to structure your part model for reliable parametric updates, that capture your design intent.

This blog post is based on an Autodesk University class, by Luke Mihelcic and Paul Munford. You can watch a recording of the class, and download a handout that goes with this presentation from the Autodesk University website here:
MFG226705: Reliable Modeling Techniques for Complex Part Design in Inventor
